Physical parameters:

•TCS3103 LIGHT-TO-VOLTAGE Three-Channel RGB Color Sensor

•_ Converts Light Intensity to Voltage

•_ Single-Voltage Supply Operation —4.5 V to 5.5 V

•_ Rail-to-Rail Output_ Programmable gain settings:− TCS3103 (2_, 4_)

•_ Low Supply Current — 270 uA Typical

•_ Fast Response Time — Rise Time = 12 us Typical

•_ Low Dark Offset

Electrical characteristics:

•ReR Irradiance responsivity, VOR: λp = 470 nm – 0.025V/(μW/cm2); λp = 524 nm – 0.095V/(μW/cm2); λp = 640 nm – 0.3 – 0.4 – 0.5V/(μW/cm2)

•ReG Irradiance responsivity, VOG: λp = 470 nm – 0.13/(μW/cm2); λp = 524 nm -0.18 – 0.25 – 0.31mV/(μW/cm2); λp = 640 nm – 0.06/(μW/cm2)

•ReB Irradiance responsivity, VOB: λp = 470 nm – 0.15 0.2 0.25/(μW/cm2); λp = 524 nm – 0.13/(μW/cm2); λp = 640 nm – 0.12/(μW/cm2)

•Gain scaling, 1× to 2× 1.9 2 2.1

•Gain scaling, 1× to 4× 3.8 4 4.2

•More details in Datasheet.
