Micro LED Transfer Technology: MLED Transfer System
Mass transfer is a critical technology for Micro LED manufacturing, transferring Micro LED to a target backplane quickly and accurately will be one of the topics that manufacturers need to work on the most as well as on improving UPH and yield. Micro LED technology are facing lots of technology challenge, there are four key technologies on Micro LED manufacturing, transfer technology takes the hardest part of manufacturing, however, driver IC, color conversion, inspection equipment and way of inspection, wafer wavelength uniformity, those are waiting for the technological bottleneck breakthrough.
Laplanda basic auto-alignment algorithm.
LS3 MLED Transfer Station.
Definitions: MLED Micro light emitting diodes; LS3 Laser soldering station of third generation; MES SQL DB Manufacturing execution software with SQL DB.
Statement: Speed of transfer MLED 300×300 array less than 60sec with 99.99% yield
FDA compliance; Automation of alignment with instant AutoZoom; Combine all devices and peripheral in one control GUI; Definition of User privileges and access, tracking parts and transfer data; MES SQL BD connection to employ data and recipes.
Solution: Newport controllers and stages; Thorlabs optics; IR by SPI 200W 1062nm; Vision acquisition: Basler acA640 750uc; Real Time processing: PXI 8880; Trigger: PXIe 6545 200 MHz; Control: PXIe 6361, X Series DAQ; Communication: 8234 Dual Gigabit Ethernet Controller; Miscellaneous custom hardware; LS3 Automation Software: IP.
Nano Scan Setup
BLUE laser (405nm) Reflective Scan
Method: Backplane reflective scanning with constant speed for set trajectory (-5mm:+5mm) to get the result of rising scan (0mm:5mm) for two independent
travel to compare
Nano Scan intended will be used to determine the linearity, coordinates and tracking of shots along the scanning path. The algorithm includes checking the quality of the backplane, the intensity and duration of each individual shot, the total number of shots, and a full report.
MLA-263 Station
MLA-263 Station Control Panel has the next functional Tabs:
Welcome STANDBY, Stage Default the settings of the position of the X,Y,R,M,MLA stages for calibrations, saving and loading to and from the configuration file, training shut, HOME, MICROSCOP positioning, LASER positioning, fixed positioning for groups, wafer detection, auto focus, position window. Video Monitor Morphological and binary transformation, threshold, saving and uploading the result 2D images. Time Loop Real Time monitoring, Start the Loop, Characterization, Methods of interpolation, Saving the interpolated data, loop time parameters. Trigger Real Time timing, pulse duration, pulse interval, pulse amplitude, delays, interpolation data, tracing and feedback.
Settings Stage parameters, Velocity, Acceleration, Positioner names and groups, loops frequency, buffer volumes, acquisition s peed. Laser single and continues shut control. Nest Wafer setting pressure control. Report time stamp, report the position versus shut, absorption index, timing, deviations, distortion, operator’s name. Configuration Real Time Tracing and Monitoring SOP standard operating procedure set of step by step instructions compiled by an organization to help workers carry out complex routine operations.
Pneumatic Nest with Manual micro-step aligning
Some applications require precise aligning of the device under the test directly before the test, on position and under the magnification. XY-Tilt Pneumatic Nest is employing this function.
Pneumatic Nest with Manual micro-step aligning precise positioning reaches 0.5μm in XY and 0.1 degree tilt.
Autonomous Pressure Control System PCS-326
PCS-326 is a system including a mini PC, built-in ATMEGA chip controller, pressure regulator and manual vacuum valve.
PCS-326 is good for applications requiring a low noise vacuum supplier.
LPLBA046 CW PW Laser Test System
LPLBA046 is a system for full characterization of the Low (up to 5W) laser beam for CW AND PW regime withing of 1-1GHz frequency domain.
⦁ Optical Power
⦁ Spatial Aspects: Beam Profiles and Beam Quality
⦁ Withing different frequency components of a laser beam
⦁ M2 factor
⦁ Beam uniformity.
⦁ Beam propagation.
⦁ Beam peak intensity from the context of Gaussian beams.
⦁ Beam pointing fluctuations.
⦁ The polarization.
⦁ Temporal and Spectral Aspects.
⦁ For pulsed lasers, measurements of the pulse energy, pulse duration and peak power.
⦁ Near Field (NF) profile.
⦁ In the case of Q-switched lasers, optical energy.
⦁ Spectrum and spectrum power.
⦁ Adjusting Optical Attenuation and absorbing neutral density filters at high power
Simple automation: Laplanda Multiple Linear Stages Controller
Convenient interface for controlling multiple stages on stepper motors by using Arduino UNO board. Five fixed positions for each stage and Homing will make the GUI control easy and reliable. This solution suggests up to three stages.
Candela 7305 Controller
Applications of photonics included all areas from everyday life to the most advanced science, e.g. light detection, telecommunications, information processing, photonic computing, lighting, metrology, spectroscopy, holography, medicine (surgery, vision correction, endoscopy, health monitoring), biophotonics, military technology, laser material processing, art diagnostics (involving InfraRed Reflectography, Xrays, UltraViolet fluorescence, XRF), agriculture, and robotics. Design and manufacture custom automation for a reliable, efficient, and innovative industrial assembly and inspection machines.
Candela 7300 Inspection Tool
Light Fixture functional optical and electrical testing require to confirm it’s performance in conformity with the original product specification. Multifunctional tester for different type and size light fixtures should be convenient for operation, fast in the result production and cost effective. Candela device in the modification with 7300 identification number is designed to fit the parameters of required tester
High Speed Prober HSP087
The four point electrical probe is a very versatile method used widely in physics for the investigation of electrical phenomena. HSP087 has especially designed two four point superconducting devices from the YBa2Cu3O7 and the Bi2Sr2Ca2Cu3O10 materials for such investigations. The Complete Exploration Kit and the Super Exploration Kit contain four point electrical probes. Newport high resolution stages are used.
CANDELA-7308 Flicker Measurement Device
Flicker – Perception of visual unsteadiness induced by a light stimulus whose luminance or spectral distribution fluctuates with time, for a static observer in a static environment. ~0-80Hz
Phantom Array – Perception of a spatially extended series of light spots when making a saccade (image transition across the retina) across a light source that fluctuates with time. ~50Hz-2kHz
Stroboscopic Effects – Change in motion perception induced by a light stimulus whose luminance or spectral distribution fluctuates with time, for a static observer in a non-static environment. ~50Hz-2kHz
Temporal Light Artifact – An undesired change in visual perception, induced by a light stimulus whose luminance or spectral distribution fluctuates with time, for an observer in a certain environment.
Wafer HV Tester (WHVT)
WHVT is a device dedicated for dielectric (strength) test, dielectric voltage-withstand test, flash test, high potential (“HiPot”) test or isolation test.
Vertical cavity mirroring station
XYZ microscope table for proprietary oxidation vertical-cavity surface-emitting laser’s glass mirroring station; LabVIEW control panel with USB interface, MFS, high speed USB microscope and step motors control.
CBCP Stage of Production Lamp Hot Tester
Device is a System that allows to perform the testing of SORAA LED product in Arts environment. The goal of CBCP Stage of Production Lamp Hot Tester is to detect the parameters of CBCP, Beam Angle and CU for tested part and characterize this part for pass/fail criteria, to determine and to describe CCT, Spectrum and other parameters declared below and to create the report.
Snap Connector Turntable Tester
The Snap Connector Turntable Tester (SCTT) upsets the status quo in wireless production test. The SCTT couples NI’s PXI vector signal transceiver (VST) and multicore processing technologies to deliver industry-leading test speeds. With faster measurements, you can reduce the cost of manufacturing test for wireless devices such as mobile phones, tablets, and infotainment systems. The SCTT supports wireless standards from LTE-A to 802.11ax to Bluetooth LE. Its advanced switching topologies are ready for multisite and MIMO test, and its software supports chipsets from top vendors such as Qualcomm and Broadcom.
Pneumatic Controller
Simplicity of design and control—Machines are easily designed using standard cylinders and other components, and operate via simple on-off control.
Reliability—Pneumatic systems generally have long operating lives and require little maintenance. Because gas is compressible, equipment is less subject to shock damage. Gas absorbs excessive force, whereas fluid in hydraulics directly transfers force. Compressed gas can be stored, so machines still run for a while if electrical power is lost.
Safety—There is a very low chance of fire compared to hydraulic oil. New machines are usually overload safe to a certain limit.
- Range: 0-80psi
- Release pressure function included (switching to negative pressure with vacuum pump – option)
- Resolution: 1psi
- Accuracy: 98%
- Interface: USB
- Software: GUI for Windows OS
Bio-Nano Laser diffractive Scanner
- fiber IR 200W laser for diffraction beam collimating with defocusing and wavelength separation;
- NI PXIe digitaizer with 250MHz sequencing ability;
- Newport nano resolution stages for high accuracy;
- laser scanning confocal microscope for imaging cells in multiple wavelengths;
- optical cell analysis with a fluorescence microscope system with high speed camera and image analysis;
- a chemical fume hood, and a general purpose autoclave;
- particle size analysis by dynamic light scattering, laser diffraction, and nanoparticle tracking techniques;
- measuring zeta potential and isoelectric point;
- characterizing particle shape;
- working with nanoparticles or other materials under controlled atmospheres with low oxygen;
- chemical synthesis for separations.
DNA Sequencer Instrument Test Bench
The Test Bench was designed to check the concept of BETA DNA Sequencer, components, software and impedance spectroscopy method as itself implemented to BETA instrument design. The result had admitted the insolvency of the method and the whole project
Chroma Meter CM-001
The parameters of CCT and CU is important part of the product characterization and that determination on a product line is an important part of the confirmation of the reliability and quality of the product. XYZ of CIE 1931 color space and u’v’ of CILUV are produced as a part of math determination the same as the lux (symbol: lx) the SI unit of illuminance and luminous emittance.
Integrating Sphere Sensors
- Calibrated and traceable to NIST standards
- Tightest calibration uncertainty specification in market
- Maximum power measurement up to 10 watts and higher
Barrel vs Flat 2’x’2′ Clear Light
Current design is not require screws, glue or other fasten elements. The enclosure from sheet metal has a clamps and force points to spring altogether. No flimsy. Lightweight (0.025” sheet metal aluminum 5053 coated)
Module – 24″ Light String
Laplanda PS-2001 LED high current no noise power supply
The noise of the power supply is a major problem for high quality LED display and CW Lasers. Laplanda PS-2001 is a 2Vout low dropout high current stabilizer with current control from 0 to 20A and NO noise.
Applications:
- High Quality LED display
- CW Lasers
- Telecommunications
- Electronics
- Uninterruptible power supplies
- Defense installations
- Aviation
- Medical equipment
- Extreme temperature environments (-65°C to +80°C)
GHT Hermeticity Tester with GPIU interface
CMOS chip for BETA DNA sequencing is designed as a hermetic device of microfluidic domain. The GHT Hermeticity tester incorporated to Epson robotic system for mass production, and also is working as an independent device.
7-Axes Microscope Stand
Device uses 7 Axes for better determination of the wire bond damages or weaks with separate low-numerical-aperture objectives with the illumination and collection axes crossed at angle θ from the midline. This architecture collects images in scattering media with high transverse and axial resolution, long working distance, large field of view, and reduced noise from scattered light. Device is able to measure transverse and axial (FWHM) resolution of 1.3 and 2.1 μm, respectively, in free space, and confirm subcellular resolution in excised esophageal mucosa. The optics may be scaled to millimeter dimensions and fiber coupled for collection of high-resolution images in vivo.
Consumer Lamp Tester and Loader
LED driver require pre-assembled testing and microcontroller flashing. This purpose is incorporated in Consumer Lamp Tester And Loader.
Consumer Lamp Tester and Bootloader
LED driver require pre-assembled testing and microcontroller flashing. This purpose is incorporated in Consumer Lamp Tester And Loader.
Module – Bagel Rainbow
Light is more than light. Light can help you see the true beauty of every color and every moment. Or calm your mind for a good night’s sleep. Light can give you more than you ever imagined.
Modular design for flat applications.
Tube 2’ Rotating Fixture
Plastic/Glass tube on wall mounted hinges with 340 degree rotating.
Perfect for kitchen, bathroom, garage…
Post Optical Linear Scanner
The light intensity (I) and color uniformity (CU) of LED light guide radiation points are required to be smooth correlated between each other during the dimming/lighting operation. LAT-001 is pointed to detect bad LEDs in string of 2’x2′ fixture.
Remote Controlled Two axes Angle Calibration Tool for Velodyne LiDAR sensors
ACT-1286
ACT-1286 uses the relationship between object size, image size , determines the difference of the distance between the reflective surface of object, calculates the radius of the reflective surface (R) and determines the distance to object. This device is used for angle determination from known positions and distance calculation with trigonometric functions uses.
Velodyne LiDAR sensor remote controlled Angle Calibration Tool
ACT-1263
ACT-1263 uses the relationship between object size (O), image size (I), the distance between the reflective surface and the object (d), and the radius of the reflective surface (R). If three of these variables are known (or fixed), the fourth can be calculated using the formula R=2dI/O
PDM24CS with custom made HMI
This all in one 4 axis motion control the PDM24CS high performance control system integrates a selection from a wide set of available components – multi-axis controllers with networking capabilities, universal drives and power supplies; providing complete control of all machine automation functions (motion, logic, power and data), resulting in shorter development cycle time, reduced risk and lower costs. Configured from a range of: Multifunctional Controllers, Universal Motor Drives, Power Supplies, Compact Enclosure’ Powerful Software Package, The Market – High Performance Production, Test and Inspection Systems. Developed for production, test and inspection equipment, such as flat panel displays, semiconductors, electronic assembly, general sub-micron automation and medical applications, the PDM24CS is the first cost-effective and flexible tailor-made solution that addresses all motion and machine control needs of demanding machinery. All in one solution: High precision, Axes synchronization, Motion and PLC, High dynamics, Complex kinematics.
Lab Functional Tester
The CMOS Functional Tester needs to be available for Fab technition in Clean Room Enviroment. The clamp adjusted nest with 260 pin’s socket is used for CMOS insert. The tester consists the internal power supply, adapter board, Opal Kelly FPGA board and single board PC. The software is combined with multiple code language and integrated under LabVIEW GUI.
Heat staking machine interface box
Low cost compact thermal device with touch screen controls and integrated system controllers. Heat staking machine interface box Features: 120V AC model (up to 6 x 350 watt heaters) and 240V AC model (up to 12 x 350 watt heaters); Digital zone heat controller (80° F to 999° F); Modular master/slave temperature controllers; Digital timer for weld time and post-cool; Easy to use LCD touch screen display; Hydraulic speed control standard; Modular configuration without knockouts and hand wiring of relays and controllers; Rewired and preprogrammed for optional slide kits, post cool, and fixture clamping; optical (zero force) safety switches.
MLA-268 Station
MLA-268 is a prototype of high speed MLED transfer tool. Trigger Real Time timing, pulse duration, pulse interval, pulse amplitude, delays, interpolation data, tracing and feedback. Settings Stage parameters, Velocity, Acceleration, Positioner names and groups, loops frequency, buffer volumes, acquisition s peed. Laser single and continues shut control. Nest Wafer setting pressure control. Report time stamp, report the position versus shut, absorption index, timing, deviations, distortion, operator’s name. Configuration Real Time Tracing and Monitoring SOP standard operating procedure set of step by step instructions compiled by an organization to help workers carry out complex routine operations.
MLA-268 Station (continuation)
MLA-268 is a prototype of high speed MLED transfer tool. Trigger Real Time timing, pulse duration, pulse interval, pulse amplitude, delays, interpolation data, tracing and feedback. Settings Stage parameters, Velocity, Acceleration, Positioner names and groups, loops frequency, buffer volumes, acquisition s peed. Laser single and continues shut control. Nest Wafer setting pressure control. Report time stamp, report the position versus shut, absorption index, timing, deviations, distortion, operator’s name. Configuration Real Time Tracing and Monitoring SOP standard operating procedure set of step by step instructions compiled by an organization to help workers carry out complex routine operations.
Velodyne LiDAR sensor compact Burn-In Station interface box
Rx-6
Pre-programmable Test Equipment power cycling program.
When Rx-6 executes a program, it must know-in real time-when external devices controlling a process are changing. During each operating cycle, the processor reads all inputs, takes these values, and energizes or de-energizes the outputs according the user program. Because the inputs can be change at any time it constantly repeats this cycle as long, as the Rx-6 is in the RUN mode.
Remote controlled Candela 7055 Photonic Sequencer
Ultra Fast Photon Spectroscopy of the DNA fragment method is developed as a sequencing the data flow of RNA polymerase molecule per cell collected using fragmentation of spectrum wavelengths of reflection of the sugar AGTC in timeline and assigning the classification to it as a particles specified in filtered data array. The mobile device can be adopted for running of most of the functions.
Precision Film Cutter
Ring removal stage require the dicing tape cut according to specification:
- On single wafers;
- On stacked wafers;
- Chips on UV-tape.
Universal Adapter and Sockets (US*)
The Universal Adapter is designed for testing of the next types of the consumer lamps: E26/27, E11, GU5.3, GU24, GU10, AR111, PAR36, PAR20, PAR30, PAR38 and similar; custom and regular parts; body injected from bakelite plastic and has melting temperature above 350 degree Celsius; E26/27 and E11 clamps injected from Zn(3) alloy and have the function of auto sockets for fast load/unload; upside down position holding confirmed; pat. pend.
Device is created for professionals to have test ability for almost all socket systems in one case.
SX-Auto Test Station CX-LS036 automated
CX-LS036 is intended to be the device for the laser beam M2 factor characterization, also called beam quality factor or beam propagation factor for measure of the beam quality of a laser beam. According to ISO Standard 11146 [6], it is defined as the beam parameter product divided by, the latter being the beam parameter product for a diffraction-limited Gaussian beam with the same wavelength.
SX-Auto Test Station CX-LS036 automated
Fast Real-Time System for Tape Scan RTTS1236
RTTS1236 is the system for the fast acquisition of the images in several different magnification with simultaneous connection with Database for the file name vs OCR recognition. The system is fully automated and require Operator just to Scan the Barcode for the Tape recognition and Data grabbing from the Database, locate the quantity (usually the maximum particle is used as a default), first start particle (usually the first particle is a default) and push the “Start Scan” button. The system will automatically adjust the exposure time for several cameras, adjust the focus for multiple locations and for all microscopes prescribed in Database information, create the planar surface for focal distance equalizing by creating the polynomial Spline trajectory for Z stage, and will move by detected coordinates and constructed ROI for different microscope offsets, with simultaneous saving the images with High Resolution quality. The system employes the Real Time Operating System that allows to perform task with maximum speed and with minimum interventions from the Operating System. The system is using three computers, three microscopes, seven linear stages, one rotational stage, three fast Basler cameras and another modern and advanced features
SX-Auto Test Station CX-LS036 automated
Fast Real-Time System for Tape Scan RTTS1236
RTTS1236 is the system for the fast acquisition of the images in several different magnification with simultaneous connection with Database for the file name vs OCR recognition. The system is fully automated and require Operator just to Scan the Barcode for the Tape recognition and Data grabbing from the Database, locate the quantity (usually the maximum particle is used as a default), first start particle (usually the first particle is a default) and push the “Start Scan” button. The system will automatically adjust the exposure time for several cameras, adjust the focus for multiple locations and for all microscopes prescribed in Database information, create the planar surface for focal distance equalizing by creating the polynomial Spline trajectory for Z stage, and will move by detected coordinates and constructed ROI for different microscope offsets, with simultaneous saving the images with High Resolution quality. The system employes the Real Time Operating System that allows to perform task with maximum speed and with minimum interventions from the Operating System. The system is using three computers, three microscopes, seven linear stages, one rotational stage, three fast Basler cameras and another modern and advanced features
Microscope Auto-Zoom MAZ-012
MAZ-012 is an automatically controlled the microscope zoom in-out add-on device with continuously keeping the focal distance to get in focus the object.
Parker motion control.
Parker motion control can be done using EtherCAT LAN communication. The speed of the response detected in a range of 10MHz
MN-12 Movable under the pressure Nest
MH-12 is a device designed to move the device under test from one test station to another while maintaining pressure in the “Nest” volume.
MH-12 constant pressure is guaranteed for 5 minutes with a pressure drop of 1% per minute.
Pneumatic Controller PK014
PK014 is intended to be used for pneumatic control of the Positive and Negative (Vacuum) Pressure in a range of -14+100 psi. The impeded application is controlling the pressure with accuracy of 1.5%
Spin Nest SN012
SN012 uses a technique of the Spin Nest for fastest sequence of particles located on Wafer or any other surface. The method of electromagnetic proximity response can be used, or the reflection by focused laser beam
Low Power Laser Beam Analyzer LPLBA046
LPLBA046 is a system for full characterization of the Low (up to 5W) laser beam for CW AND PW regime withing of 1-1GHz frequency domain.
⦁ Optical Power
⦁ Spatial Aspects: Beam Profiles and Beam Quality
⦁ Withing different frequency components of a laser beam
⦁ M2 factor
⦁ Beam uniformity.
⦁ Beam propagation.
⦁ Beam peak intensity from the context of Gaussian beams.
⦁ Beam pointing fluctuations.
⦁ The polarization.
⦁ Temporal and Spectral Aspects.
⦁ For pulsed lasers, measurements of the pulse energy, pulse duration and peak power.
⦁ Near Field (NF) profile.
⦁ In the case of Q-switched lasers, optical energy.
⦁ Spectrum and spectrum power.
⦁ Adjusting Optical Attenuation and absorbing neutral density filters at high power
High frequency waveform amplifier Tester HFPT036
HFPT036 is addressed to the measurement technique for high-frequency characterization. The method created is a characterization of the frequency-domain amplification and analysis. Two approaches employed as a frequency-domain analysis of circuits and its roots in analogue system design. Time-domain analysis is integrated for digital IC-design. It will be shown that frequency- and time-domain analyzers deliver compatible and complimentary results. The instrument described in this chap and can measure the black-box description or signal integrity characteristics of a package or interconnection under test.
